ABB F202 AC-40/0,03, Residual Current Circuit Breaker (RCCB), 2 Pole, 30mA, 40A, AC [F202 AC-40/0,03]

• ABB F202 AC-40/0,03, Residual Current Circuit Breaker (RCCB), 2 Pole, 30mA, 40A, AC
• The RCCBs F200 series assures Protection to people and installations against fault current to earth.
• A large offer for standard instantaneous and selective AC and A types is completed with some configurations for special applications.
• A large offering for standard instantaneous and selective AC and A types
• All sizes up to 63 mA with sensitivity thresh olds up to 1 A are offered in all possible pole configurations
• ABB RCDs carry many marks and approvals for the worldwide market
• Suitable for Protection against AC earth leakage current
• Can be used as a main device providing ground fault Protection against earth leakage for several MCB branch devices

Technical

• Standards: IEC 61008
• Operating Characteristic: Instantaneous
• Type of Residual Current: AC type
• Rated Residual Current:30mA
• Rated Current (In): 40A
• Number of Poles: 2
• Power Loss:at Rated Operating Conditions per Pole 2.4 W
• Ambient Air Temperature:Operation -25 … +55 °C
• Storage -40 … +70 °C
